Fire Trainer / Flame Generator Gf42

Flame simulator trainer GF42 Fire Extinguisher Trainer And Accessories LeaderFlame simulator trainer GF42 Fire Extinguisher Trainer And Accessories Leader

Compact, lightweight, water-free, easy to transport and install, it generates flames of 3.9 ft high on 4.5 ft².

  • EASY TO CARRY
    Compact (24.8″ wide and 27.5″ long) and lightweight (31.5 lbs), GF42 can be easily transported and stored in a car trunk.
  • QUICK AND EASY SET-UP
    Fire trainer without water, GF42 requires no preparation before use (no water filling, etc.).

Features

  • Flame simulator trainer GF42 Fire Extinguisher Trainer And Accessories Leader
  • Flame simulator trainer GF42 Fire Extinguisher Trainer And Accessories Leader
  • Flame simulator trainer GF42 Fire Extinguisher Trainer And Accessories Leader

PRODUCT CHARACTERISTICS

Compact, lightweight, GF42 fire trainer is easy to carry in a vehicle trunk. Water-free, it is simple and quick to set-up. With a fire surface area of 4.5 ft², it generates flames with a maximum height of 3.9 ft.

More Videos

Data Sheet

GENERAL CHARACTERISTICS

FIRE TRAINER Without water
SIZE ON THE GROUND 27.6″ x 24.8″
FLAMES Up to 3.9 ft high
THERMAL RADIATION FELT Appropriate
TRAINEE SAFETY Flexible connector with stop pedal (option) or Solenoid valve module (option)
MOBILITY Small size to be easily shipped by car.

FIRE TRAINER

FIRE TRAINER DIMENSIONS L 27.6″ x D 24.8″ x H 0.9″
WEIGHT 31.5 lbs
FIRE SURFACE AREA 4.5 ft²
FIRE TRAINER WITH WATER no
FLAME HEIGHT up to 3.9 ft
REMOTE CONTROLS 1 wired remote control
SAFETY Solenoid valve optional
GAS SUPPLY CONNECTION Screw-in connector
MATERIAL Stainless steel
WARRANTY 1 year for fire trainer and gas supply

FUEL SUPPLY CONSOLE

No

WIRED REMOTE CONTROL

CONTROL HANDLER Push-button with protection against accidental ignition
WATERPROOF Yes to splashing water
ELECTRIC CABLE length 19.7 ft – fire resistance (standard IEC 331)
POWER SUPPLY 9V-6LR61 batteries (not supplied)

WIRELESS REMOTE CONTROL

ARMOURED GAS SUPPLY HOSE

LENGTH 19.7 ft, in accordance with EN 559
NOMINAL FLOW RATE 26.5 lbs/h
CONNECTION to connect on industrial-type propane gas bottles without flow limiter

GAS SUPPLY KIT – DOMESTIC GAS BOTTLES

TO CONNECT TWO BOTTLES OF DOMESTIC PROPANE GAS (WITH FLOW LIMITER) TO HAVE A FLAME HEIGHT SIMILAR TO THAT GENERATED BY INDUSTRIAL PROPANE BOTTLES (WITHOUT FLOW LIMITER).

Downloads

Cutsheet PDF Product Manual PDF
