Electric Fan On Battery Batfan 2 - 45min 10,420 CFM*

Batfan ll 45 Side View Firefighting Equipment TempestBatfan ll 45 Side View Firefighting Equipment Tempest

Lightweight, portable and autonomous (battery-powered), it allows great operational flexibility for firefighters.

  • Multi-use

    It can be used:

    • Indoor and outdoor: IP66
    • For PPV, alone or combined with other fans
    • For blowing or extraction through ducts
    • As a foam generator with adapter
    • for rehab of the crew after intervention
  • Autonomous and Lightweight
    Works on battery or mains power. 45 minutes autonomy for only 58.4 lbs.
  • NiMH battery
    NiMH batteries are not considered hazardous materials. Unlike Lithium batteries, they can be transported without problems in the air.
  • Convenient and ergonomic
    • Adjustable tilt from +65° to -90° with locking system (allows flat positioning to cover a manhole)
    • Integrated variable-speed drive
    • 10 LEDs to illuminate the walkway in front of the blower
    • Built in charger: charge during operation
    • Battery charge indicator
    • Secure (flat) keypad to control all functions (no fragile button to turn for setting speed)
    • Low maintenance: 1 full charge every 6 weeks
    • Designed to be connected with ducts, foam adapter and rehab misting device

Features

  • Electric fan on Battery Leader Fans

PRODUCT CHARACTERISTICS

MULTI-APPLICATION BATFAN 2

is the most versatile battery-powered fan on the market. It can be used for PPV (offensive, defensive, combined), blowing, extraction and it can be transformed into a foam generator or rehab misting device

COMPACT, MOBILE AND AUTONOMOUS

Lightweight and equipped with a carrying handle and strap, it is portable by one person. Folds up and stows easily in the trunk of a vehicle. Two BATFAN occupy the space of one conventional fan. Equipped with one NiMH battery, BATFAN 2 allows independent fire operations.

QUICK AND EASY SET-UP BATFAN

is quicker to set-up than conventional fans. Thanks to its battery, BATFAN 2 is completely autonomous and can be started instantly without wasting time looking for a power outlet.

Introducing BATFAN 2 electric fan on battery – 45 min

Discover BATFAN 2, the most versatile LEADER battery-powered fan on the market: PPV, extraction, blowing, misting, foam generator, etc.

Data Sheet

GENERAL CHARACTERISTICS

OPEN AIRFLOW 16,510 cfm
PPV FLOW RATE ACCORDING TO AMCA 240 10,420 cfm
WEIGHT  58.4 lbs.
DIMENSIONS W X H X D Retracted: 21.25″ x 21″ x 10.6″
PROPELLER DIAMETER 16.5″
AUTONOMY 45 min at full speed / 3h30 at 60%
ENGINE 600W with variable-speed drive – IP66
POWER SUPPLY Self-contained: NiMH battery
Connected: Single-phase 110V – 50/60 Hz or 220V – 50/60 Hz
ELECTRICAL SAFETY Meets NF EN 50178 standard for user safety (leakage current less than 3.5 mA)
CONSUMPTION IN STEADY OPERATION 4A when connected to 220V / 8A when connected to 110V
POWER SUPPLY PLUG CE–110V male plug
CHARGING AND BALANCING TIME 7h20 for a discharge of 45 min
PROTECTION IP66
RESISTANCE Designed to withstand a 2m drop
NOISE LEVEL 76.8 dB at 10 ft
VENTILATION TYPE PPV, combined PPV and Extraction
TILT from +65° to -90°
LIGHTING 10 LED
MATERIAL Rotationally molded HDPE
WARRANTIES BATfan – 2 years / Battery – 1 year
