Large-flow ventilator EASY 2000 trailer-mounted - 129,400 cfm Open Air

LARGE-FLOW VENTILATOR EASY 2000 Leader FansLARGE-FLOW VENTILATOR EASY 2000 Leader Fans

It is ideal for ventilation of industrial units, medium/high-rise buildings and underground parking lots.

  • LARGE FLOW
    EASY 2000 large-flow ventilator is the best in its class. With a flow rate of 129,400 cfm Open Air, it allows smoke removal and cooling of large volumes (covered/closed parking lots, warehouses, production lines, exhibition halls, etc.).
  • EASY TO OPERATE BY ONE PERSON
    Thanks to its extremely low weight (less than 716 lbs), EASY 2000 LFV (Large-Flow Ventilator) is very easy to operate by one person.
  • ADAPTABLE TO ALL TYPES OF VEHICLES

    EASY 2000 large-flow ventilator is available in two versions to meet different configurations:

    • On Skid: can be used on a forklift truck, trolley, tracked vehicle or on a vehicle bed (pick-up type)
    • Trailer-mounted
  • MANY OPTIONS AVAILABLE
    EASY 2000 large-flow ventilator can be equipped with many options such as 23 in or 47 in lifting table, LED headlight, exhaust extension, blowing or suction ducts, etc.

Features

  • LARGE-FLOW VENTILATOR EASY 2000 Leader Fans
  • LARGE-FLOW VENTILATOR EASY 2000 Leader Fans
  • LARGE-FLOW VENTILATOR EASY 2000 Leader Fans
  • LARGE-FLOW VENTILATOR EASY 2000 Leader Fans

PRODUCT CHARACTERISTICS

EASY 2000 large-flow ventilator is the best in its class! With a flow rate of 129,400 cfm Open Air, it allows smoke removal and cooling of large volumes (covered/closed parking lots, warehouses, production lines, medium/high-rise buildings, exhibition halls, etc.).

Alone, it is an effective response to ventilate large volumes.
Several, they offer flexibility of action because they can be used simultaneously to optimise the blowing power. They can also be distributed at various strategic points of a city.

DATA SHEET

GENERAL CHARACTERISTICS

OPEN AIR FLOW 129,400 cfm
WEIGHT Without elevation:663 lbs
Elevation 23.6″ : 888 lbs
Elevation 47.2″ : 985 lbs
DIMENSIONS W X H X D Without elevation: 110″ x 67.52″ x 56.3″
Elevation 23.6″: 110″ x 75.4″ x 56.3″
Elevation 47.2″: 110″ x 80.7″ x 56.3″
PROPELLER DIAMETER 34.8″
SUPPORT Single-axle trailer with brakes, towball and sealed enclosure
ENGINE CONTROL PANEL yes
WIRED REMOTE CONTROL yes
MISTING SYSTEM For water or water+additives – 65 GPM @ 100 PSI
ENGINE HONDA GX630.
ENGINE POWER 20.8 HP
TANK 4.7 gallons
FUEL Unleaded petrol SP95
AUTONOMY 3h05
OIL Engine oil: 5W-30 synthetic API SJ or later (CASTROL MAGNATEC)
Hydraulic oil for lifting option: CASTROL SAF XJ 75-140
BATTERY 12V / 44 Ah battery to power the electrical equipment
NOISE LEVEL 93.9 dB at 23 ft
VENTILATION TYPE PPV
APPLICATION Ventilating underground parking lots, industrial sites, warehouses, tunnels, etc.
