Large-flow ventilator EASY 4000 on Skid - 234,430 cfm Open Air

LARGE-FLOW VENTILATOR EASY 4000 Leader FansLARGE-FLOW VENTILATOR EASY 4000 Leader Fans

Perfect for ventilation of very large volumes like tunnels, industrial sites, airport halls, etc.

  • LARGE FLOW
    EASY 4000 large-flow ventilator is the most efficient ventilator in LEADER range. With a flow rate of 234,430 cfm Open Air, it allows smoke removal and cooling of very large volumes (tunnels, industrial sites, airport halls, etc.).
  • ADJUSTABLE TILT
    EASY 4000 large-flow ventilator is equipped with a Large Format shroud of 47.2″ diameter with adjustable tilt from -10° to +20° controlled from the control panel.
  • Optional 23.6 in and 47.2 in lift system
    EASY 4000 can be mounted on an elevation platform of 23.7 in or 47.2 in.
  • MANY OPTIONS AVAILABLE
    EASY 4000 large-flow ventilator can be equipped with many options such as LED headlight, exhaust extension, blowing or suction ducts, and manual 360° rotation system.

Features

  • LARGE-FLOW VENTILATOR EASY 4000 Leader Fans
  • LARGE-FLOW VENTILATOR EASY 4000 Leader Fans
  • LARGE-FLOW VENTILATOR EASY 4000 Leader Fans
  • LARGE-FLOW VENTILATOR EASY 4000 Leader Fans

PRODUCT CHARACTERISTICS

A true mobile solution for very large volume ventilation, EASY 4000 large-flow ventilator has a flow rate of 234,430 cfm Open Air. It allows smoke removal and cooling of very large volumes such as tunnels, industrial sites, very high-rise buildings, airport
halls, industrial complexes and exhibition centres.

DATA SHEET

GENERAL CHARACTERISTICS

OPEN AIR FLOW 234,430 cfm
WEIGHT Without elevation: 820 lbs
Elevation 23.6″ : 1042 lbs
Elevation 47.2″ : 1142 lbs
DIMENSIONS W X H X D Without elevation: 71.2″ x 63.7″ x 58″
Elevation 23.6″ : 71.2″ x 70.4″ to 94″ x 66.53″
Elevation 47.2″ : 71.2″ x 75.7″ to 122.9″ x 58″
PROPELLER DIAMETER 47.2″
SUPPORT Steel chassis painted in black epoxy (all delivered on pallet)
ENGINE CONTROL PANEL yes
WIRED REMOTE CONTROL yes
MISTING SYSTEM For water or water+additives – 65 GPM at 100 PSI
ENGINE BMW Flat Twin – 1170 cm³ with electronic control – 2 cylinders – 4-stroke.
ENGINE POWER 115 HP
TANK 11 gallons
FUEL Unleaded petrol SP95
AUTONOMY 1h40
OIL Engine oil: 3.8 l – API SL
Hydraulic oil for lifting option: 0.9 l – ISO32
BATTERY Rapid charge 12V / 15 Ah battery to power the electrical equipment
NOISE LEVEL 96 dB at 23 ft
VENTILATION TYPE PPV
APPLICATION Ventilating underground parking lots, industrial sites, warehouses, tunnels, very tall buildings, etc.
