Portable Foam Unit Uprim

Portable Foam Unit Uprim LEADERPortable Foam Unit Uprim LEADER

UPRIM: portable foam unit of low or medium expansion

  • Capacity of 40 extinguishers
    With a capacity of 2.6 gallons of foam concentrate and the possibility of dosing the UPRIM (portable foam unit) at 1%, once connected to a power source it can generate up to 264 gallons of premixture, i.e. up to 13,208 gallons of medium-expansion foam.
  • Easy to use
    Simply connect the UPRIM to a fire-hose station or a fire engine to instantly have a foam generation system perfect for typical operations: car fire, fume suppression, prevention before welding, etc.
  • Robust
    Thanks to its rotationally moulded anti-corrosion tank in polyethylene, its stainless steel dip tube and the choice of materials used, the UPRIM is almost indestructible.
  • Multi-Application
    Depending on the type of operation and foam concentrate injected, the UPRIM can be used either with its low-expansion foam nozzle (for a range between 15.7 and 31.9 ft) or with its medium-sized nozzle.

Features

  • Portable Foam Unit Uprim LEADER

product characteristics

Specially designed for firefighting, the UPRIM has a 2.6-gallon foam concentrate tank and the extinguishing capacity of more than 40 extinguishers. Easy to use, simply fill it with foam concentrate through its large filling port and connect it to a water supply (fire-hose station, etc.).
Its flow rate is 15.8 gpm. The UPRIM is very robust and rustproof with its indestructible rotationally moulded tank in polyethylene. Reliable and precise with its ability to dose the foam concentrate to 1, 3 or 6%, and ergonomic with its wide carrying case, the UPRIM produces low or medium expansion foam thanks to its two types of rapidly interchangeable nozzles.
It is a compact, economical and versatile tool for vehicle fires, suppression of toxic fumes or protection against possible fires in industrial facilities (prevention before welding).

Data Sheet

GENERAL CHARACTERISTICS

FLOW RATE 15.8 gpm
OPERATING PRESSURE 3 to 10 bar
DOSAGE 1%, 3%, 6%
CAPACITY 2.6 gallons
INLET 1” BSP F
NOZZLE BF= low expansion
MF= medium expansion
QUICKLY INTERCHANGEABLE NOZZLE Yes
EXPANSION BF= 8-10
MF= 50-70
RANGE BF= 13.2 to 29.5ft
MF= 9.8 to 16.7ft
TARE WEIGHT BF= 7.1 lbs
MF= 7.8 lbs
DIMENSIONS W X H X D BF= 24.8″ x 10.5″ x 7.3″
MF= 24.8″ x 14.4″ x 7.3″
CARRYING CASE Yes
OPTION Inlet coupling (GFR or DSP40)

Downloads

Cutsheet PDF Product Manual PDF
