Mobile Ventilation Unit MVU-48

Mobile Ventilation Unit MVU-48 Firefighting Equipment Tempest BlowersMobile Ventilation Unit MVU-48 Firefighting Equipment Tempest Blowers

The MVU™ 48 is a slightly scaled down version of our MVU™ 60, about 4,000 lbs lighter in fact.

  • Massive 48″ Seven Blade Aluminum Impeller
    The combined massive 48” (1.2 meters) seven (7) blade aluminum impeller and steel shroud are capable of generating air movement unlike any other ventilation unit around.
  • Massive Air Movement
    With its calculated 380,000 nominal Open Air CFM (645,624 m3/hr), the 48 is able to complete nearly any ventilation job in minutes, if not seconds; saving precious time, money, resources, and possibly even lives.
  • Hydraulic Powered
    Like the MVU™ 60, all of the 48’s mechanical actions, including the fan’s blade rotation, are powered by a reliable hydraulic system. The hydraulic pressures are generated by its turbocharged Cummins Diesel engine, mounted under the MVU’s™ silencer hood. Every MVU™ 48 is custom built by Tempest’s team of engineers and fabricators.
  • Optional Features
    The MVU™ 60 proudly offers a number of options in addition to its standard features that are designed to help you overcome any unique challenges you may face in your specific application. From ventilator lift, the rotation, to a high volume water misting system, these options give you the power to pick and choose exactly what you need to ensure you’re properly equipped to ventilate effectively and efficiently.
  • Scissor Lift Option
    The optional Scissor Lift package allows the unit to be easily elevated on level ground to the height of up to nearly 10′ (3 meters). The lifting action is delivered through hydraulic pressures generated by the engine.
  • Ventilator Tilt Option
    Available with an optional Tilt Package which allows the ventilators to be directed either 30° up or down, greatly increasing the unit’s ability to ventilate elevated or lowered areas. Tilt controls are powered by the hydraulic pressure system.
  • Ventilator Rotation Option
    The ventilators can be rotated 380° continuously, in either direction with the Ventilator Rotation Option. The rotation action is powered by a 24V electric motor
  • Misting System Option
    Incredibly valuable in a number of scenarios such as hazmat, decontamination, and general cooling, the Misting System Option allows you to throw 87 GPM of water through 8 misting nozzles up to 130′ (40 meters) downstream from the ventilator.
  • Controls
    Unit controls are electronic and electronic over hydraulic by both fixed panel with controls and a wired or wireless remote control.
  • Unit Mounting
    Tempest offers a number of mounting options for the MVU™ 48. Some platforms include custom tandem axle trailers, domestic and foreign commercial truck chassis, rail cars, hook-lift skid systems, and more. All of these mounts can be custom ordered and installed through Tempest.

Features

  • Mobile Ventilation Unit MVU-48 Firefighting Equipment Tempest Blowers
  • Mobile Ventilation Unit MVU-48 Firefighting Equipment Tempest Blowers

PRODUCT CHARACTERISTICS

The Tempest MVUTM 48 is a slightly scaled-down version of our MVUTM 60, about 4,000 lbs (1,814 kg) lighter in fact. As the name implies, it showcases a still massive 48” (1.2 meters) seven (7) blade aluminum impeller and steel shroud. With its calculated 380,000 nominal Open Air CFM (645,624 m3/hr), the 48 is able to complete nearly any ventilation job in minutes, if not seconds; saving precious time, money, resources, and possibly even lives. Although it’s smaller than the 60, it sacrifices almost none of the performance to achieve its reduced weight and more compact size.

Mobile Ventilation Unit MVU-48



DATA SHEET

TYPE Mobile Ventilation Unit (MVU®)
BLADE 48″ Diameter Aluminum Air Foil Design, 7 Blade Impeller
FRAME Tubular and Solid Steel Welded Construction
SHROUD Rolled and Formed Steel
GRILLE Continuous Circular Wound External-Weld Steel Wire with Welded Tie-Points
MOTOR/DRIVE 110 HP Turbo Charged Cummins® Diesel Powered Hydraulics
MOUNT Tandem Axle Trailer, Import/Domestic Truck Chassis, Hook – Lift Skid, Rail Car, Other
CONTROLS Full Functional Electronic Fixed Panel Controls with Wired or Wireless Remote
Blade Engine HP CFM Weight
48″ Turbo Charged Cummins® Diesel 110 380,000 (Nominal Open Air) 8,000 lbs

DOWNLOADS

Cutsheet PDF Product Manual PDF
